- Head swivels 90 vertically; START / STOP switch incorporates emergency STOP
- Adjustable gibs on table precision; adjustable stops on table
- Straightforward gear drive mechanism; 0-2500RPM spidle speed
- Chuck arbor bolt provides tightening of drilling chuck through the spindle
- Rack and pinion feed for drilling operations; metric leadscrews available
- Safety guard with microswitch according to EU-requirements
NOTE:
Please slow down the machine before converting high-speed mode into low-speed mode, or the gear may break down
Specification:
Drilling Capacity: 16mm
Max. Face Mill Capacity: 30mm
Max. End Mill Capacity: 13mm
Spindle Stroke: 180mm
Longitudinal Travel: 250mm
Cross Travel: 100mm
Spindle Rotary Angle: -45~+45
Working Table Size: 410 x 112mm
Motor Power:600WMax. 650W
Max. Distance Spindle to Table: 220mm
Spindle Taper: R8
Spidle Speed: 0-2500RPM
Net Weight/Gross Weight: 136.7 lb. /176.4 lb.
Packing Size: 640 x 565 x 720mm
Package List:
1 x Milling Machine
1 x Wrench (36)
1 x Drill Chuck
1 x Oiler
1 x Handle Lever
4 x Hex Wrenches (2, 2.5, 3, 4, 5, 6, 8)
1 x Hook Spanner (45-52)
1 x Double End Wrench (8-10, 13-16)
1 x Drill Chuck Wrench
3 x Handles
4 x T-shape Nuts
4 x Nuts (M8)
4 x Double End Bolts (M8X60)
1 x Fuse (8A)
1 x Suspender
1 x Instruction
- 0-2500RPM spidle speed
- Adjustable gibs on table precision
- Head swivels ?90? vertically
